High Feed Speed Plate Chamfering Machine Stainless Steel Light Weight

Zhejiang Wellnit Mechanical Technology Co.,Ltd
Contact Now

High Feed Speed Plate Chamfering Machine Stainless Steel Light Weight

Brand Name : Wellnit

Model Number : PB-60

Certification : ISO9001

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T

Supply Ability : 30 sets a month

Delivery Time : Within 7days after we received 100% payment

Packaging Details : Plywood

Power : AC 380V 50Hz

Total : 3400W

Spindle Speed : 1050r/min

Feed speed : 0-1500mm/min

Milling Width : 0-40mm

Spindle Milling Width : 10-15mm

Slope Angle : 10°-60°(adjustable)

Clamping thickness : 6-40mm

Holding the minimum plate width : 100mm

Machining steel plate length : 〉200mm

Worktable Height : 820-860mm

Weight : 250kg

Processing Materials : Carbon Steel,Stainless steel,Aluminum alloy,Composite Plate

Contact Now

High Feed Speed Plate Chamfering Machine Stainless Steel Light Weight






Main performance of the product


  PB-60 is a small, light weight, simple operation, high efficiency automatic marching milling machine,

groove angle and groove depth can be adjusted, large and small plates can be used, processing speed

and milling machine, no inferior. The machined groove surface is as high as Ra3.2~6.3, which completely

meets the welding requirements of pressure vessels.


Compare with traditional plate milling machine

The milling head runs more smoothly and reliably, its feed system and return system are completely

independent, return speed is fast, efficiency is high, the angle of milling cutter head is adjusted

conveniently, custom cutter head and standard cutter head are interchangeable, which is a new

generation of traditional milling machine.



Technical Parameter




Model



PB-60


Power Supply



AC 380V 50HZ



Total



3400W


Spindle Speed



1050r/min


Feed Speed



0~1500mm/min


Milling Width



0~40mm


Single Milling Width



10-15mm


Slope Angle



10°~60°(Adjustable)


Clamp Thickness



6~40mm


Holding the minimum plate Width



100mm


Machining steel plate length



〉200mm




Processing Materials



Carbon Steel, Stainless Steel,

Aluminium Alloy, Etc




High Feed Speed Plate Chamfering Machine Stainless Steel Light WeightHigh Feed Speed Plate Chamfering Machine Stainless Steel Light Weight

Operation adjustment

1. loosen the nut on both sides of the scale, adjust the groove angle through the blue handle.

2. release the black plastic handle and adjust the groove depth through the silver metal knob behind the

machine.

3. Adjust the height of the machine (for sheets with workbenches) by rotating the plastic handle on the

caster.




product application

Automatic marching milling machine is widely used in boiler, pressure vessel manufacturing industry,

shipbuilding, electric power, petroleum, chemical machinery, construction machinery manufacturing, for all

kinds of low-carbon steel plate, stainless steel plate and aluminum plate before welding groove

processing, bevel, straight edge, U groove can be one-time milling molding, compared with planer, has a

price Low, low energy consumption, high efficiency, high degree of finish, easy operation and

maintenance.
